| 品牌 | 日本东丽 |
| 货号 | 0078 |
| 用途 | 家电 电器 汽车等行业 |
| 牌号 | CM3004G-20 |
| 型号 | CM3004G-20 |
| 品名 | PA66 |
| 外形尺寸 | 2mm |
| 生产企业 | 广裕塑胶 |
| 是否进口 | 是 |
物性表
| Filler / Reinforcement |
Glass Fiber, 15% Filler by Weight
|
| Additive |
Flame Retardant
|
| Features |
Chemical Resistant
Flame Retardant
High Strength
|
| Uses |
Appliances
Camera Applications
Cell Phones
Communication Applications
Computer Components
Connectors
Displays
Electrical Housing
Electrical/Electronic Applications
Insulation
Lighting Applications
Office Automation Equipment
Printer
Switches
Video Equipment
White Goods & Small Appliances
|
| Processing Method |
Injection Molding
|
| ISO Designation |
>PA66-GF15FR(17)<
|
| PHYSICAL |
Dry
|
Conditioned
|
Unit
|
Test Method
|
| Density (23°C) |
1.47
|
--
|
g/cm3
|
ISO 1183 |
| Molding Shrinkage 4 | Internal Method | |||
| Across Flow : 3.00 mm |
0.80 to 1.2
|
--
|
%
|
|
| Flow : 3.00 mm |
0.40 to 0.60
|
--
|
%
|
|
| Water Absorption 5 | ISO 62 | |||
| 24 hr, 23°C |
0.40
|
--
|
%
|
|
| Saturation, 23°C |
5.0
|
--
|
%
|
| MECHANICAL |
Dry
|
Conditioned
|
Unit
|
Test Method
|
| Tensile Stress | ISO 527-2 | |||
| -40°C |
145
|
--
|
MPa
|
|
| 23°C |
125
|
95.0
|
MPa
|
|
| 80°C |
60.0
|
--
|
MPa
|
|
| Tensile Strain | ISO 527-2 | |||
| Break, -40°C |
2.5
|
--
|
%
|
|
| Break, 23°C |
3.0
|
3.0
|
%
|
|
| Break, 80°C |
4.5
|
--
|
%
|
