| 品牌 | 日本宝粒 |
| 货号 | E4008L |
| 用途 | 薄壁制品 |
| 牌号 | E4008L |
| 型号 | E4008L |
| 品名 | LCP |
| 外形尺寸 | 2*3mm |
| 生产企业 | 广裕塑胶 |
| 是否进口 | 是 |
PHYSICAL
Nominal Value
Unit
Test Method
Density / Specific Gravity
1.70
g/cm3
ASTM D792, ISO 1183
Spiral Flow
Internal Method
-- 4
0.300
cm
-- 5
0.700
cm
-- 6
1.90
cm
-- 7
3.50
cm
-- 8
0.300
cm
-- 9
0.800
cm
-- 10
2.50
cm
-- 11
4.60
cm
Molding Shrinkage
Internal Method
Flow : 3.00 mm
0.10
%
Across Flow : 3.00 mm
1.3
%
Water Absorption (24 hr, 23°C)
0.020
%
ASTM D570
MECHANICAL
Nominal Value
Unit
Test Method
Tensile Modulus
11900
MPa
ISO 527-1
Tensile Strength
--
150
MPa
ASTM D638
--
103
MPa
ISO 527-2
Tensile Elongation
Break
5.0
%
ASTM D638
Break
3.1
%
ISO 527-2
Flexural Modulus
--
12300
MPa
ASTM D790
--
12900
MPa
ISO 178
Flexural Strength
--
139
MPa
ASTM D790
--
153
MPa
ISO 178
IMPACT
Nominal Value
Unit
Test Method
Charpy Unnotched Impact Strength
54
kJ/m2
ISO 179/1eU
Unnotched Izod Impact
--
520
J/m
ASTM D256
--
43
kJ/m2
ISO 180/1U
HARDNESS
Nominal Value
Unit
Test Method
Rockwell Hardness (R-Scale)
106
ASTM D785
THERMAL
Nominal Value
Unit
Test Method
Deflection Temperature Under Load
0.45 MPa, Unannealed
345
°C
ASTM D648, ISO 75-2/B
1.8 MPa, Unannealed
326
°C
ASTM D648
1.8 MPa, Unannealed
304
°C
ISO 75-2/A
CLTE
ISO 11359-2
Flow : 50 to 150°C
1.4E-5
cm/cm/°C
Transverse : 50 to 150°C
6.2E-5
cm/cm/°C
